StudioLive 64S Series III
The Most Formidable StudioLive Yet
The StudioLive 64S is a powerhouse — it’s PreSonus’s most formidable offering yet. This 64-channel digital mixer boasts a quad-core FLEX DSP engine with enough muscle to drive 526 simultaneous processors, and then some. What’s more, its FLEX FX multi-effects processor vaunts eight slots of reverb emulations and delays with eight dedicated effects buses. Benefit from easy expandability thanks to built-in AVB networking. Enjoy versatile operation by virtue of the 64S’s 32 Flex Mixes. Shape and polish each channel to perfection courtesy of PreSonus’s lauded Fat Channel processing. The PreSonus StudioLive 64S includes a comprehensive software suite, which enables you to make top-flight recordings right from the get-go.
Tech Specs
- Type:Digital Mixer
- Channels:64 channels, 76 mix channels
- Inputs - Mic Preamps:32 x XLR-1/4" combo (mic/line)
- Phantom Power:Switchable per channel
- Inputs - Line:1 x Dual RCA Stereo (tape), 4 x 1/4" (2 x stereo aux in)
- Outputs - Main:2 x XLR (main out), 1 x XLR (mono/center), 2 x 1/4" (monitor)
- Outputs - Other:16 x XLR (mix out), 1 x Dual RCA Stereo (tape)
- Outputs - Digital:1 x XLR (AES/EBU)
- Busses/Groups:32 x FlexMix Buses (aux, subgroup, matrix), 43 total mix buses, 24 x DCA groups
- Talkback:1 x XLR (phantom power)
- Data I/O:1 x Locking Ethernet (AVB audio network), 1 x RJ45 (network control)
- USB:1 x Type B (64 x 64)
- Computer Connectivity:USB 2.0
- Bluetooth:v4.1
- Headphones:1 x 1/4"
- Faders:33 x Touch-sensitive motorized faders
- A/D Resolution:24-bit/48kHz
- Effects:FLEX FX Multi-effects processor, 8 x effects slots, 8 x effects buses
- Signal Processing:Fat Channel plug-ins, 10 x EQs, 10 x Compressors
- Transport Controls:Yes
- DAW Control:Advanced Studio One, MCU Logic emulation, HUI Pro Tools emulation
- Screen:7" Touchscreen
- Storage:SD card recorder (34 track)
- Software:Studio One Artist, UC Surface (Mac, Windows, Android, iPad), QMix-UC App (iOS, Android), Presonus Capture
- Power Source:Standard IEC AC cable
- Height:6.51"
- Depth:22.97"
- Width:32.37"
- Weight:37.2 lbs.
- Manufacturer Part Number:STUDIOLIVE 64S
